Scooter Pathrider 130 Xl 4 Red [Pr130Xl-4R]

The Pathrider® 130 XL features a powerful drivetrain and large 33 cm (13”) pneumatic wheels to handle rugged outdoor terrain. Luxury touches like a wraparound easy drive tiller, low-profile non-marking tyres, seat post suspension for a smoother ride and an LED kerb light blend seamlessly giving the Pathrider 130 XL a sleek, sporty style.

Features

• Large 33 cm (13”) pneumatic tyres for excellent outdoor performance
• Full lighting package including directional signals and angle- adjustable, dual bulb lower headlight
• Seat post suspension for a smoother ride
• Easy drive tiller with wraparound handles
• Front basket standard
• Easily accessible tie down points (for transport of unoccupied scooter)
• Rear view mirror standard

Options

• Rear basket
• Safety flag
• Walker holder
• Durable weather cover

Technical Information

• Weight capacity: 158.75 kg (350 lbs.)
• Maximum speed 1: Up to 12.4 km/h (7.7 mph)
• Ground clearance 2: 11.4 cm (4.5”)
• Turning radius 2: 167.6 cm (66”)
• Overall length 2: 135.9 cm (53.5”)
• Overall width 2: 63.5 cm (25”)
• Front tyres: 10 cm x 33 cm (4” x 13”) pneumatic
• Rear tyres: 10 cm x 33 cm (4” x 13”) pneumatic
• Seat-to-deck: 46 cm (18”)
• Seat-to-ground: 63 cm - 67 cm (25” - 26”)
• Suspension: Front & rear
• Range per charge 1,4: Up to 24.99 km (15.53 miles)
• Maximum obstacle climbing ability: 12 cm (4.72”)
• Total weight without batteries 2,5: 101.1 kg (223 lbs.)
• Heaviest piece when disassembled: 42.9 kg (94.5 lbs.) (front section)
• Standard seating
• Type: CRS Deluxe
• Weight: 22.5 kg (49.5 lbs.)
• Material: Black Vinyl
• Dimensions:
• width - 45 cm (18”) (overall width)
• depth - 45 cm (18”) (effective depth)
• height - 47.6 cm (18.75”)
• Drive system: Rear-wheel drive, sealed transaxle, 24-volt DC motor
• Dual braking system: Regenerative and electromechanical
• Battery requirements 3: Two 12-volt, deep cycle
• Size: 55 AH (standard)
• Weight 6: 55 AH: 16.6 kg (36.5 lbs.) each
• Battery charger: 5-amp, off-board
• Warranty: 2-year limited

1 Varies with user weight, terrain type, battery amp-hour (AH), battery charge, battery condition and tyre condition. This specification can be subject to a variance of (+ or -) 10%. 2 Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+ or - 3%). 3 AGM or gel cell type required. 4 Tested in accordance with ANSI/RESNA, WC Vol2, section 4 & ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance test conducted at maximum weight capacity. 5 Includes standard seat. 6 Battery weight may vary based on manufacturer. NOTE: This product conforms to all applicable ANSI/RESNA testing requirements and ISO 7176 series EN12184 standards. All specifications subject to change without notice.
